Internal & External Low Flow Air Atomizing Spray Nozzles
Design Features of the XA10/XA11 Low Flow Spray Nozzles
- Highly atomized spray at low flow rates
- Internal and external mix set-ups
- Eight distinct types of sprays with interchangeable nozzle air and fluid caps
- Compatible with XAAD, XAEF (pictured), XAER, XAFF, XAPF, XAPR, XASF, XASR, and XAXW spray set-ups
Choosing Automatic Air Atomizing Nozzles
- If you desire a smaller drop size than can be achieved with a single-fluid hydraulic nozzle and are working with low pressure, a two-fluid air atomizing nozzle is an excellent choice.
- A two-fluid air atomizing design is often the best option when a viscous fluid needs to be sprayed/atomized and cannot be sprayed with a hydraulic single-fluid nozzle.
Product Specifications
| Inlet Cooling | ¼” NPT or BSPP, Liquid and air |
| Liquid Flow Rate | 72 GPH / 272.5 LPH Max |
| Rated Liquid Pressure | 60 PSI / 2.8 bar |
| Operating Temperature Range | -15° F to 400° F / -26° C to 204° C |
| Air Cylinder Pressure | 30 PSI to 250 PSI / 2 bar to 17.2 bar |
| Max Cycle Frequency | 3 cycles / sec |
| Material | Nickel-plated brass or stainless steel wetted components, Blue-Gard® gasket, Viton® (FKM) seals |
