Simple. Compact. Tough.
For simple, low pressure, industrial dosing, the Rapide range is a compact, peristaltic tube range of pumps which can be installed as a unit in itself or integrated into a system such as a printing press or packaged turnkey skid. Suitable for rugged environments, the range uses an IP55 rated gear motor and is assembled in a heavy duty aluminum housing. The tube is 'thick-walled' for the safe and reliable handling of abrasive, corrosive and viscous fluids such as chemical solutions, fine slurry, inks, dyes, additives and other dosing fluids. Choose from Verderprene or Silicone Tubing Materials.
Benefits
- Easily integrated into existing equipment
- Ideal for liquid transfer
- Easily controlled by external inverters
- IP55 Protection
Models
|
R2S |
R3 |
R3DC |
R3S |
R5000 |
|
 |
 |
 |
 |
 |
|
| Maximum Flow |
93.6 l/h
|
230 l/h
|
3.4 l/min
|
189 l/h
|
365 l/h
|
| Maximum Discharge Pressure |
2 bar
|
2 bar
|
2 bar
|
2 bar
|
2 bar
|
| Maximum Temperature |
85 °C
|
85 °C
|
85 °C
|
85 °C
|
85 °C
|
| Maximum Tube |
8 mm
|
9.6 mm
|
9.6 mm
|
9.6 mm
|
9.6 mm
|
| Tube Wall Thickness |
2.4 mm
|
3.2 mm
|
3.2 mm
|
2.4 mm
|
2.4 mm
|
| Certificates |
FDA. USP
|
FDA. USP
|
-
|
FDA. USP
|
-
|
| Download Datasheet | Click to Download | Click to Download | Click to Download | Click to Download | Click to Download |
|
R6 |
R7S |
R8 |
R12 |
R17S |
|
 |
 |
 |
 |
|
|
| Maximum Flow |
380 l/h
|
375 l/h
|
470 l/h
|
840 l/h
|
1020 l/h
|
| Maximum Discharge Pressure |
2 bar
|
2 bar
|
2 bar
|
2 bar
|
2 bar
|
| Maximum Temperature |
85 °C
|
85 °C
|
85 °C
|
85 °C
|
85 °C
|
| Maximum Tube |
12.7 mm
|
15.9 mm
|
12.7 mm
|
15.9 mm
|
19.0 mm
|
| Tube Wall Thickness |
3.2 mm
|
3.2 mm
|
3.2 mm
|
4.8 mm
|
4.8 mm
|
| Certificates |
FDA. USP
|
FDA. USP
|
FDA. USP
|
FDA. USP
|
FDA. USP
|
| Download Datasheet | Click to Download | Click to Download | Click to Download | Click to Download | Click to Download |
