Specifications
| Design Standard | API 609 DIN 3354 EN 593 BD 5155 |
| Size Range | 3" - 88" |
| Pressure Rating | PN10 PN16 Class 150 |
| Working Temperature | -10˚C ~ +80˚C 14˚F ~ +176˚F |
| End Connection | ANSI B16.1 ANSI B16.5 ANSI B16.1 ASME B16.47 DIN 2501 BS 4505 EN 1092-2 |
| Face-to-Face | ISO 5752 SERIES 13/14 DIN 3202-F4 |
| Test & Inspection | API 598 DIN 3230 EN 1266-1 |
| Materials | Body : Ductile Iron | WCB | Stainless Steel Disc : Ductile Iron | AI-Bronze | Stainless Steel | Nylon | PTFE Seat : EPDM | NBR | Viton |
