Grooved End Swing Check Valves are compact check valves with end connection compliant with AWWA C606 standard.
Features
- Connection compatible with Victaulic joints.
- High strength ductile iron body used for lowering the weight and improving long term durability.
- All iron parts are coated inside & outside with fusion bonded epoxy for corrosion resistance per AWWA C550.
- Bronze Seat Ring reduces wear and tear.
- Plug on the body for bypass, draining and cleaning.
- Check valve conforms to the requirements of UL 312 & FM class 1210.
- NSF61 certified valve available as option.
Specifications
| Design Standard | AWWA C606 |
| Size Range | 2” – 12” |
| Pressure Rating | 300 psi |
| Working Temperature | -10˚C ~ +80˚C 14˚F ~ +176˚F |
| End Connection | AWWA C606 |
| Materials | Body : Ductile Iron Disc : Stainless Steel |
