Features
- The ball moves fully out of the flow path to reduce head loss.
- High strength ductile iron body used for lowering the weight and improving long term durability.
- All iron parts are coated inside & outside with fusion bonded epoxy for corrosion resistance per AWWA C550.
- Valves can be installed in the horizontal or vertical position.
- Top cover provides access to the inside of the valve without removal from the pipe line.
- A wash out plug can be added upon request to allow for cleaning and maintenance operation.
Specifications
| Size Range | 2” – 24” |
| Pressure Rating | 250 psi |
| Working Temperature | -10˚C ~ +80˚C 14˚F ~ +176˚F |
| End Connection | Ductile Iron Ductile Iron + EPDM |
| Face-to-Face | AWWA C508 |
| Test & Inspection | AWWA C508 API 598 |
| Materials | Body : Ductile Iron Ball: Ductile Iron + NBR Encapsulated |
