SEEPEX D – METERING PUMPS
SEEPEX D metering pumps achieve a metering accuracy of ±1%. They’re used wherever low to highly viscous media, media containing solids and chemically corrosive media are processed and all with low pulsation and to the exact drop. 6 Models are available.
SEEPEX D METERING PUMPS FEATURES AND BENEFITS
- Modular system for quick and easy conversion
- Low pulsation pumping
- High metering accuracy (deviation ±1%)
- Easy maintenance due to the plug-in connection
- Material combinations available for all conveying products
- Multiple drive combinations possible
SEEPEX D – MD METERING PUMPS
SEEPEX MD are compact units with a high metering accuracy. The stainless steel or synthetic material casings are highly compatible with chemically corrosive media.
SEEPEX MD METERING PUMPS FEATURES AND BENEFITS
- For low to highly viscous media, as well as shear-sensitive and chemically aggressive media
- Conveying capacity: 0.2 l/h – 1,000 l/h (0.053 USGPH – 264 USGPH)
- Pressure: up to 24 bar (360 PSI)
- Short, compact design with directly flange-mounted drive (block type)
- Casing of stainless steel or synthetic material
- High metering accuracy
- High corrosion resistance due to the variety of components made of Hastelloy C or titanium
- Low maintenance costs
SEEPEX D – MDP METERING PUMPS
SEEPEX MDP range pumps are available with stainless steel or synthetic casing. Along with stators made of PTFE, these pumps handle and meter hydrocarbon-containing media such as paints, varnishes, solvents, plasticizers and others.
SEEPEX MDP FEATURES AND BENEFITS
- For low to highly viscous media as well as shear-sensitive and chemically aggressive media
- Conveying capacity: 1 l/h – 500 l/h (0.264 USGPH – 132 USGPH)
- Pressure: up to 12 bar (180 PSI)
- Single-part, jointless and wear-resistant rotating unit made of synthetic material
- Reduced costs due to inexpensive rotating unit
- Easy maintenance
SEEPEX D – MDT METERING PUMPS
SEEPEX MDT Metering Pumps have an open hopper with cylindrical compression zone. The auger feed screw on the coupling rod feeds the viscous product to the rotor and stator.
SEEPEX MDT METERING PUMPS FEATURES AND BENEFITS
- For highly viscous products with low flowability
- Conveying capacity: 5 l/h – 500 l/h (1.32 USGPH – 132 USGPH)
- Pressure: up to 24 bar (360 PSI)
- Open hopper pump with compression zone and auger feed screw
- High volumetric efficiency with optimum filling of the conveying chamber due to the system pressure produced in the compression zone
SEEPEX D – MDC METERING PUMPS
SEEPEX MDC Pumps are equipped with open aseptic fork joints. The pumps meet the highest hygienic requirements as well as providing corrosion and wear resistance.
SEEPEX MDC METERING PUMPS FEATURES AND BENEFITS
- For highly viscous products with low flowability
- Conveying capacity: 0.5 l/h – 500 l/h (0.132 USGPH – 132 USGPH)
- Pressure: up to 24 bar (360 PSI)
- Highest hygienic standards as well as corrosion and wear resistance
- 3-A Sanitary Standards
- FDA approved
- Particularly easy to maintain (open joint consisting of only a few components)
- Guaranteed residue-free: open aseptic fork joint with CIP cleaning
SEEPEX D – MDTC METERING PUMPS
SEEPEX MDTC Pumps have an open hopper with a cylindrical/conical compression zone. The auger feed screw on the coupling rod processes the viscous product into the cavities of rotor and stator.
SEEPEX MDTC METERING PUMPS FEATURES AND BENEFITS
- For highly viscous products with low flowability
- Conveying capacity: 0.5 l/h – 500 l/h (0.132 USGPH – 132 USGPH)
- Pressure: up to 24 bar (360 PSI)
- Open hopper pump with cylindrical/conical compression zone and auger feed screw
- Open aseptic fork joint
- 3-A Sanitary Standards
- FDA approved
- Particularly easy to maintain (open joint from the MDC range consisting of only a few components)
- Guaranteed residue-free: open aseptic fork joint with CIP cleaning
- Optimum filling of the conveying chamber due to the system pressure produced in the compression zone
SEEPEX D – MDF METERING PUMPS
SEEPEX MDF Metering Pumps are used for draining barrels.
SEEPEX MDF METERING PUMPS FEATURES AND BENEFITS
- For non-viscous to viscous media
- Conveying capacity: 0.5 l/h – 1,000 l/h (0.132 USGPH – 264 USGPH)
- Pressure: up to 12 bar (180 PSI)
- Draining pump for open top barrels or closed barrels with 2″ bung holes
- Low weight, easy to transport with the handle
- Problem-free barrel emptying due to the suction side inlet pressure
