    KINETROL Rotary Actuators – Quarter-Turn Pneumatic Actuator Range

    Kinetrol engineered the first rotary vane actuators in 1958. The rotary design is based upon a single moving part which eliminates additional parts required to convert linear motion to rotary motion. This simple and innovative design provides a highly accurate and extremely reliable actuator for operating valves, drives and dampers, and is perfectly suited for the most demanding process control control applications.

    • Torque outputs up to 168000 lbf ins (19140 Nm)
    • A single moving part
    • Compact size combined with high torque output
    • Easy double-acting to spring-return conversion
    • Very accurate modulation for quarter-turn control valves.
    • Dual-opposed, low friction lip seals for extremely long life
    • Totally enclosed spring housing, not exposed to corrosive atmospheres
    • No pressure retaining shaft seals or O-Rings
    • Fast operation with large ports and no air restrictions
    • 80-100 deg. rotation standard, adjustable and fixed



    GENERAL SPECIFICATIONS

    • Casing: Models 0M0, 01, 02, 03, 05 & 07 Pressure die cast ZL16 zinc alloy. Models 08, 09, 10, 12, 14, 15, 16, 18, 20 & 30 Die cast or sand cast aluminium alloy.
    • Vane & Output Shaft: Models 0M0, 01, 02, 03 and 05 stainless steel. Models 07 to 30 SG iron, zinc plated.
    • Shaft Bushes: PTFE coated bronze.
    • Seals: Moulded polyurethane. High and low temperature seals also available – contact Kinetrol.
    • Seal Expanders: Stainless spring steel. Couplings: Weldable mild steel, zinc plated.
    • Working Temperature Range: -20°C (-5°F) to 80°C (175°F). High temperature option up to 100°C (212°F) using temperature seals and higher temperatures with special equipment. *Low temperature option down to -40°C (-40°F) include option “L” at end of actuator coding. *Contact us for Atex Approval rating.
    • Maximum Recommended Working Pressure: 100 psi (7 bar) Maximum overload pressure: 150 psi (10 bar)



    OPTIONS

    All of Kinetrol’s modular options provides the functionality and control you need in an easy to mount, space savings package.

    Model-0M-150x150

    Model 0M

    Operating Specifications
    • Output Torque:  8.0 lbf ins/0.9 Nm at 100 psi/7 bar
    • Angle of Travel (adjustable):  80° – 100° (restricted travel versions available)
    • Displaced Volume:  0.15 in3/2.4 cm3
    • Finish:  Epoxy stove enamel
    • Weight:  0.26 lb/0.12 kg
    Model-01-150x150

    Model 01

    Operating Specifications
    • Output Torque:  58 lbf ins/6.7 Nm at 100 psi/7 bar
    • Angle of Travel (adjustable):  See Catalogue (restricted travel versions available)
    • Displaced Volume:  1.00 in3/16.5 cm3
    • Finish:  Epoxy stove enamel
    • Weight:  See catalogue
    Option Packages Include:
    • Fail Safe Spring Return Unit

    atex-approved-cat-1
    Model-02-150x150

    Model 02

    Operating Specifications
    • Output Torque: 106 lbf ins/12.1 Nm at 100 psi/7 bar
    • Angle of Travel (adjustable): 80° – 100° (restricted travel versions available)
    • Displaced Volume: 1.89 in3/31 cm3
    • Finish: Epoxy stove enamel
    • Weight: 0.97 lb/0.44 kg (excluding coupling)
    Option Packages Include:
    • Fail Safe Spring Return Unit
    • Female drive spring
    • ISO adaptor

    atex-approved-cat-1
    Model-03-150x150

    Model 03

    Operating Specifications
    • Output Torque:  220 lbf ins/25 Nm at 100 psi/7 bar
    • Angle of Travel (adjustable):  80° – 100° (restricted travel versions available)
    • Displaced Volume:  3.66 in3/60 cm3
    • Finish:  Epoxy stove enamel
    • Weight:  1.53 lb/0.70 kg (excluding coupling)
    Option Packages Include:
    • Limit Switch Boxes for Open/Close Indication – Various Switches for Hazardous Areas
    • Solenoid Valve
    • AP Pneumatic Positioner
    • EL Electropneumatic Positioner
    • P3 On/Off Positioner Including Hazardous Areas
    • Clear Cone Position Monitor
    • Female Drive Spring
    • ISO Adaptor

    atex-approved-cat-1
    Model-05-150x150

    Model 05

    Operating Specifications
    • Output Torque:  440 lbf ins/50 Nm at 100 psi/7 bar
    • Angle of Travel (adjustable):  80° – 100° (restricted travel versions available)
    • Displaced Volume:  6.9 in3/113 cm3
    • Finish:  Epoxy stove enamel
    • Weight:  2.73 lb/1.24 kg (excluding coupling)
    Option Packages Include:
    • Limit Switch Boxes for Open/Close Indication – Various Switches for Hazardous Areas
    • Solenoid Valve
    • Fail  Safe Spring Return Unit
    • AP Pneumatic Positioner
    • EL Electropneumatic Positioner
    • P3 On/Off Positioner Including Hazardous Areas
    • Clear Cone Position Monitor
    • Female Drive Spring
    • ISO Adaptor
    • Spring to Center
    • Geared Manual Override

    atex-approved-cat-1
    Model-07-150x150

    Model 07

    Operating Specifications
    • Output Torque:  1080 lbf ins/124 Nm at 100 psi/7 bar
    • Angle of Travel (adjustable):  80° – 100° (restricted travel versions available)
    • Displaced Volume:  18.3 in3/300 cm3
    • Finish:  Epoxy stove enamel
    • Weight:  6.91 lb/3.13 kg (excluding coupling)
    Option Packages Include:
    • Limit Switch Boxes for Open/Close Indication – Various Switches for Hazardous Areas
    • Solenoid Valve
    • Fail  Safe Spring Return Unit
    • AP Pneumatic Positioner
    • EL Electropneumatic Positioner
    • P3 On/Off Positioner Including Hazardous Areas
    • Clear Cone Position Monitor
    • Female Drive Spring
    • ISO Adaptor
    • G3/8 or 3/8 NPT Air Port Option Available
    • Spring to Center
    • Geared Manual Override

    atex-approved-cat-1
    Model-08-150x150

    Model 08

    Operating Specifications
    • Output Torque: 1740 lbf ins/199 Nm at 100 psi/7 bar
    • Angle of Travel (adjustable):  80° – 100° (restricted travel versions available)
    • Displaced Volume:  29.6 in3/485 cm3
    • Finish:  Epoxy stove enamel
    • Weight:  5.60 lb/2.54 kg (excluding coupling)
    Option Packages Include:
    • Limit Switch Boxes for Open/Close Indication – Various Switches for Hazardous Areas
    • Solenoid Valve
    • Fail  Safe Spring Return Unit
    • AP Pneumatic Positioner
    • EL Electropneumatic Positioner
    • P3 On/Off Positioner Including Hazardous Areas
    • Clear Cone Position Monitor
    • Female Drive Spring
    • ISO Adaptor
    • Spring to Center
    • Geared Manual Override

    atex-approved-cat-1
    Model-09-150x150

    Model 09

    Operating Specifications
    • Output Torque:  2280 lbf ins/261 Nm at 100 psi/7 bar
    • Angle of Travel (adjustable):  80° – 100° (restricted travel versions available)
    • Displaced Volume:  b39.3 in3/644 cm3
    • Finish:  bEpoxy stove enamel
    • Weight:  b6.91 lb/3.86 kg (excluding coupling)
    Option Packages Include:
    • Limit Switch Boxes for Open/Close Indication – Various Switches for Hazardous Areas
    • Solenoid Valve
    • Fail  Safe Spring Return Unit
    • AP Pneumatic Positioner
    • EL Electropneumatic Positioner
    • P3 On/Off Positioner Including Hazardous Areas
    • Clear Cone Position Monitor
    • Female Drive Spring
    • ISO Adaptor
    • Spring to Center
    • Geared Manual Override

    atex-approved-cat-1
    Model-10-150x150

    Model 10

    Operating Specifications
    • Output Torque:  3625 lbf ins/416 Nm at 100 psi/7 bar
    • Angle of Travel (adjustable):  78° – 100° (restricted travel versions available)
    • Displaced Volume:  62.5 in3/1025 cm3
    • Finish:  Epoxy stove enamel
    • Weight:  12.3 lb/5.6 kg (excluding coupling)
    Option Packages Include:
    • Limit Switch Boxes for Open/Close Indication – Various Switches for Hazardous Areas
    • Solenoid Valve
    • Fail  Safe Spring Return Unit
    • AP Pneumatic Positioner
    • EL Electropneumatic Positioner
    • P3 On/Off Positioner Including Hazardous Areas
    • Clear Cone Position Monitor
    • Female Drive Spring
    • ISO Adaptor
    • Spring to Center
    • Geared Manual Override

    atex-approved-cat-1
    Model-12-150x150

    Model 12

    Operating Specifications
    • Output Torque:  5000 lbf ins/575 Nm at 100 psi/7 bar
    • Angle of Travel (adjustable):  80° – 102° (restricted travel versions available)
    • Displaced Volume:  86 in3/1410 cm3
    • Finish:  Epoxy stove enamel
    • Weight: 15.2 lb/6.9 kg (excluding coupling)
    Option Packages Include:
    • Limit Switch Boxes for Open/Close Indication – Various Switches for Hazardous Areas
    • Solenoid Valve
    • Fail  Safe Spring Return Unit
    • AP Pneumatic Positioner
    • EL Electropneumatic Positioner
    • P3 On/Off Positioner Including Hazardous Areas
    • Clear Cone Position Monitor
    • Female Drive Spring
    • ISO Adaptor
    • Spring to Center
    • Geared Manual Override

    atex-approved-cat-1
    Model-14-150x150

    Model 14

    Operating Specifications
    • Output Torque:  12000 lbf ins/1375 Nm at 100 psi/7 bar
    • Angle of Travel (adjustable):  80° – 100° (restricted travel versions available)
    • Displaced Volume:  201 in3/3294 cm3
    • Finish:  Epoxy stove enamel
    • Weight:  29.5 lb/13.4 kg (excluding coupling)
    Option Packages Include:
    • Limit Switch Boxes for Open/Close Indication – Various Switches for Hazardous Areas
    • Solenoid Valve
    • Fail  Safe Spring Return Unit
    • AP Pneumatic Positioner
    • EL Electropneumatic Positioner
    • P3 On/Off Positioner Including Hazardous Areas
    • Clear Cone Position Monitor
    • Female Drive Spring
    • ISO Adaptor
    • Spring to Center
    • Geared Manual Override

    atex-approved-cat-1
    Model-15-150x150

    Model 15

    Operating Specifications
    • Output Torque:  20337 lbf ins/2337 Nm at 100 psi/7 bar
    • Angle of Travel (adjustable):  80° – 100° (restricted travel versions available)
    • Displaced Volume:  361 in3/5920 cm3
    • Finish:  Epoxy stove enamel
    • Weight:  46.2 lb/21.0 kg (excluding coupling
    Option Packages Include:
    • Limit Switch Boxes for Open/Close Indication – Various Switches for Hazardous Areas
    • Solenoid Valve
    • Fail  Safe Spring Return Unit
    • AP Pneumatic Positioner
    • EL Electropneumatic Positioner
    • P3 On/Off Positioner Including Hazardous Areas
    • Clear Cone Position Monitor
    • Female Drive Spring
    • ISO Adaptor
    • Spring to Center
    • Geared Manual Override

    atex-approved-cat-1
    Model-16-150x150

    Model 16

    Operating Specifications
    • Output Torque:  27000 lbf ins/3100 Nm at 100 psi/7 bar
    • Angle of Travel (adjustable):  80° – 100° (restricted travel versions available)
    • Displaced Volume:  465 in3/7630 cm3
    • Finish:  Epoxy stove enamel
    • Weight:  82.5 lb/37.4 kg (excluding coupling)
    Option Packages Include:
    • Limit Switch Boxes for Open/Close Indication – Various Switches for Hazardous Areas
    • Solenoid Valve
    • Fail  Safe Spring Return Unit
    • AP Pneumatic Positioner
    • EL Electropneumatic Positioner
    • P3 On/Off Positioner Including Hazardous Areas
    • Clear Cone Position Monitor
    • Female Drive Spring
    • ISO Adaptor
    • Spring to Center
    • Geared Manual Override

    atex-approved-cat-1
    Model-18-150x150

    Model 18

    Operating Specifications
    • Output Torque:  60000 lbf ins/6900 Nm at 100 psi/7 bar
    • Angle of Travel (adjustable):  80° – 100° (restricted travel versions available)
    • Displaced Volume: 1048 in3/17170 cm3
    • Finish:  Epoxy stove enamel
    • Weight: 157.4 lb/71.4 kg (excluding coupling)
    Option Packages Include:
    • Limit Switch Boxes for Open/Close Indication – Various Switches for Hazardous Areas
    • Solenoid Valve
    • Fail  Safe Spring Return Unit
    • AP Pneumatic Positioner
    • EL Electropneumatic Positioner
    • P3 On/Off Positioner Including Hazardous Areas
    • Clear Cone Position Monitor
    • Female Drive Spring
    • ISO Adaptor
    • Spring to Center
    • Geared Manual Override

    atex-approved-cat-1
    Model-20-150x150

    Model 20

    Operating Specifications
    • Output Torque:  112000 lbf ins/12760 Nm at 100 psi/7 bar
    • Angle of Travel (adjustable):  80° – 100° (restricted travel versions available)
    • Displaced Volume:  2034 in³/33350 cm³
    • Finish:  Epoxy stove enamel
    • Weight:  416.9 lb/195.6 kg (excluding coupling)
    Option Packages Include:
    • Limit Switch Boxes for Open/Close Indication – Various Switches for Hazardous Areas
    • Solenoid Valve
    • Fail  Safe Spring Return Unit
    • AP Pneumatic Positioner
    • EL Electropneumatic Positioner
    • P3 On/Off Positioner Including Hazardous Areas
    • Clear Cone Position Monitor
    • Female Drive Spring
    • ISO Adaptor
    • Spring to Center
    • Geared Manual Override

    atex-approved-cat-1
    Model-30-150x150

    Model 30

    Operating Specifications
    • Output Torque:  168000 lbf ins/19140 Nm at 100 psi/7 bar
    • Angle of Travel (adjustable):  80° – 100° (restricted travel versions available)
    • Displaced Volume:  3050 in3/50025 cm3
    • Finish:  Epoxy stove enamel
    • Weight:  601.91 lb/273 kg (excluding coupling)
    Option Packages Include:
    • Limit Switch Boxes for Open/Close Indication – Various Switches for Hazardous Areas
    • Solenoid Valve
    • Fail  Safe Spring Return Unit
    • AP Pneumatic Positioner
    • EL Electropneumatic Positioner
    • P3 On/Off Positioner Including Hazardous Areas
    • Clear Cone Position Monitor
    • Female Drive Spring
    • ISO Adaptor
    • Spring to Center
    • Geared Manual Override

    atex-approved-cat-1

    Resources

    Kinetrol-Rotary-Actuator-Catalogue-2020

    Kinetrol-Rotary-Actuator-Catalogue-2020

    Download

    Talk to one of our Experts

    Reach out to our team of Spraying, Pumping, Filtering, Valve, and Systems Specialists today. We know we can help you with any municipal or industrial application challenges.
