Hydra-Cell P600 Series Pumps Electronic Precision Metering
Versatile, Reliable Pumps for a Wide Range of Applications
- Designed to handle a wide range of fluids from clear water to thick slurries
- Electronic flow control increases accuracy and reliability
- Multiple diaphragm design provides linear, virtually pulse-less flow
- Smaller footprint saves valuable space
- One pump covers a wide range of flows and pressures - reducing inventory requirements with fast, simple field conversion
- Duplexing option doubles capacity and equipment savings
- Hydraulically-actuated, balanced diaphragms provide superior performance across entire pressure range
- Rugged construction with a variety of affordable choices for liquid end, diaphragm and check valve materials
| Maximum Flow Rate: | 890.3 gph |
| Maximum Pressure: | 1000 psi (69 bar) for Metallic Pump Heads |
| 350 psi (24 bar) for Non-metallic Pump Heads |
Hydra-Cell P600 Series Pump Specifications
________________________________________________________________________________________________________________________
| Diaphragms per Liquid End | 3 |
| Flow Control | Electronic variable speed drive |
| Maximum Discharge Pressure | |
| Metallic Heads: | 1000 psi (69 bar) |
| Non-metallic Heads: | PVDF- 350 psi (24 bar) |
| Polypropylene- 250 psi (17 bar) | |
| Maximum Inlet Pressure | 250 psi (17 bar) |
| Maximum Operating Temperature | |
| Metallic Heads: | 250 ̊F (121 ̊C)* |
| Non-metallic Heads: | 140 ̊F (60 ̊C) |
| Inlet Port | 1-1/2 inch NPT or BSPT |
| Discharge Port | 1 inch NPT or BSPT |
| Weight (less motor)** | |
| Metallic Heads: | 146.0 lbs (66.2 kg) |
| Non-metallic Heads: | 111.0 lbs (50.3 kg) |
| Dimensions (less motor)** | |
| Metallic Heads: | 10.74” W x 20.64” D x 11.57” H |
| (272.7 mm W x 524.3 mm D x 293.9 mm H) | |
| Non-metallic Heads: | 10.74” W x 21.56” D x 11.57 H” |
| (272.7 mm W x 547.6 mm D x 293.9 mm H) | |
| * Consult factory for correct component selection for temperatures from 160 ̊F (71 ̊C) to 250 ̊F (121 ̊C). | |
| ** For 56C motor frame only. Consult factory for other motor frame sizes. | |
________________________________________________________________________________________________________________________
Hydra-Cell Pumps for Mining, Tunneling, Quarrying & Dust Suppression
Applications by Mining Market
- Borehole Stabilization (Injecting bentonite and other substances)
- Liquid Explosives (Charging liquid explosives into blast holes and rigs)
- Drill Head Cooling (Cooling the picks and coal cutters and tunneling machines while reducing dust generation)
- Hazardous Chemical Pumping (Metering hazardous solutions in metal extraction)
- Conveyor Cleaning (24/7 continuous duty in high-pressure jet cleaning)
- Gland Seal Flushing (Protecting large slurry pumps from seal damage)
- Gas Extraction (Powering a Venturi jet pump to lift drillhole water and release gas to the surface)
Have a Fluid Handling Problem? We can help you find a Pumping Solution.
John Brooks Company caters to diverse industries, offering suitable pump solutions for nearly all fluid handling needs - including yours! Our success hinges on fostering a collaborative partnership with you, where we help you find a tailored solution to enhance your systems, boost productivity, and minimize operational expenses
Consult with a John Brooks Company Pump expert today to help you determine the most suitable pump type for your application needs.
