Hydra-Cell P500 Series Pumps Electronic Precision Metering
Versatile, Reliable Pumps for a Wide Range of Applications
- Designed to handle a wide range of fluids from clear water to thick slurries
- Electronic flow control increases accuracy and reliability
- Multiple diaphragm design provides linear, virtually pulse-less flow
- Smaller footprint saves valuable space
- One pump covers a wide range of flows and pressures - reducing inventory requirements with fast, simple field conversion
- Duplexing option doubles capacity and equipment savings
- Hydraulically-actuated, balanced diaphragms provide superior performance across entire pressure range
- Rugged construction with a variety of affordable choices for liquid end, diaphragm and check valve materials
| Maximum Flow Rate: | 425.9 gph |
| Maximum Pressure: | 2500 psi (172 bar) for Metallic Pump Heads |
| 350 psi (24 bar) for Non-metallic Pump Heads |
Hydra-Cell P500 Series Pump Specifications
________________________________________________________________________________________________________________________
| Diaphragms per Liquid End | 5 |
| Flow Control | Electronic variable speed drive |
| Maximum Discharge Pressure | |
| Metallic Heads: | 2500 psi (172 bar) |
| Maximum Inlet Pressure | 500 psi (34 bar) |
| Maximum Operating Temperature | |
| Metallic Heads: | 250 ̊F (121 ̊C)* |
| Inlet Port | 1-1/4 inch NPT or BSPT |
| Discharge Port | 3/4 inch NPT or BSPT |
| Weight (less motor)** | |
| Metallic Heads: | 192.1 lbs (88.5 kg) |
| Dimensions (less motor)** | |
| Metallic Heads: | 14.5” W x 24.0” D x 13.9” H |
| (368.3 mm W x 609.6 mm D x 353.1 mm H) | |
| * Consult factory for correct component selection for temperatures from 160 ̊F (71 ̊C) to 250 ̊F (121 ̊C). | |
| ** For 56C motor frame only. Consult factory for other motor frame sizes. | |
________________________________________________________________________________________________________________________
Hydra-Cell Pumps for Mining, Tunneling, Quarrying & Dust Suppression
Applications by Mining Market
- Borehole Stabilization (Injecting bentonite and other substances)
- Liquid Explosives (Charging liquid explosives into blast holes and rigs)
- Drill Head Cooling (Cooling the picks and coal cutters and tunneling machines while reducing dust generation)
- Hazardous Chemical Pumping (Metering hazardous solutions in metal extraction)
- Conveyor Cleaning (24/7 continuous duty in high-pressure jet cleaning)
- Gland Seal Flushing (Protecting large slurry pumps from seal damage)
- Gas Extraction (Powering a Venturi jet pump to lift drill hole water and release gas to the surface)
