Versatile, Compact Vane Axial Blowers are rugged and economical ventilators that deliver exceptional air flow in a compact, lightweight design. Their non-corrosive injection-molded housings are nearly indestructible. The COPPUS Cadet is ideal for confined space ventilation of underground utilities and light manufacturing facilities. Hazardous and non-hazardous location models are available; multiple electrical options are available as well.
Features and Advantages of the COPPUS Cadet
- Non-corrosive, flame-resistant, injection-molded housings
- Carrying handle
- Fixed guide vane for optimal performance
- Safety screens per OSHA; plated steel
- Easily attach 8” duct (203 mm) to inlet & outlet
- Glass-reinforced, polyester resin, spark-resistant fan blade
- Reversible, locking, inlet flange for ducted and non-ducted applications
- 60 Hz or 50 Hz AC motors
- 115V or 230V (60 Hz), and 110V or 220V (50 Hz) options available
- Auto thermal overload protection
- 15 ft (4.57 m) cord
- Plug end (115V only)
- 88 dBA @ 5 ft (1.5 m)
Features and Advantages of the VAC
- Non-hazardous location applications only
- Yellow polycarbonate/ABS blended stationary components
- Motor – single speed, ½ HP, totally enclosed
- Rocker on/off switch
Features and Advantages of the VEP
- Hazardous & non-hazardous location applications
- Black static dissipating components
- Motor – single speed, ½ HP, explosion proof
- Hazardous location motors rated NEC Class I, Division I, Group D & Class II, Division I, Groups E, F & G specifications
- Pull ring switch
Accessories
- 8” Heavy Duty Duct (VAC)
- 8” Poly-vinyl Duct (VAC)
- 8” Conductive Duct (VEP)
- 8” Duct Storage Canister
Dimensions
Performance
| AIR FLOW THROUGH DUCT (90° DEGREE BENDS) | ||||||||
| Cadet | Free Air | 1-90° | 2-90° | 3-90° | ||||
| cfm | m3/hr | cfm | m3/hr | cfm | m3/hr | cfm | m3/hr | |
| VAC1 / VEP1 | 867 | 1,465 | 776 | 1n318 | 766 | 1,301 | 756 | 1,284 |
| VAC2 / VEP2 | 804 | 1,358 | 730 | 1,240 | 720 | 1,223 | 710 | 1,206 |
| VAC3 / VEP3 | 867 | 1,465 | 776 | 1,318 | 766 | 1,301 | 756 | 1,284 |
| VAC4 / VEP4 | 804 | 1,358 | 730 | 1,240 | 720 | 1,223 | 710 | 1,206 |
| FREE AIR DECIBEL LEVEL | |
| Cadet | 88 dBa |
