Powerful Submersible Rotating Tank Cleaner
BETE HydroWhirl Disc tank cleaning nozzles can be entirely submerged without clogging and the powerful fan spray inserts provide superior cleaning performance.
BETE HydroWhirl Disc Design Features
- Robust flat spray nozzle inserts
- Ideal for cleaning medium-sized tanks up to 11ft/3.6 m diameter
- Suitable for food and beverage applications, being made from FDA-compliant, 316L Stainless steel material
- Fluid-driven, self-flushing
- Entirely submersible, clog-resistant
- Greatest capacity free-spinning design
- Hydrostatic wear-free PTFE slide bearing for longer life
How Spray Pattern is Achieved
- The HydroWhirl® Disc tank cleaning nozzle directs the cleaning water through a rotating head at the tip of the spray assembly and produces a vigorous moving spray action against all areas of the walls of a tank.
- The spray pattern from the HydroWhirl Disc head uses impact and repetition to wash the tank quickly.
| Available Spray Angle | Flow Rate Range |
|
360° |
25.3 to 61.1 gpm |
| Available Connection Types | Material |
|
316L / PTFE |
BETE HydroWhirl Disc Tank Cleaning Nozzles Efficiently Clean Tanks and Equipment
