Interchangeable Nozzle Tips With Base and Gasket
Introducing BETE EZFF Quick Connect Deflected Fan Nozzles, an exceptional innovation in fluid dispersion technology. These fan spray nozzles offer rapid and tool-free interchangeability, with a three-part design featuring a base, gasket, and interchangeable tip, along with an exclusive ramped engagement for effortless alignment. This groundbreaking design not only ensures efficient spray performance but also provides versatility with threaded adapters that can accommodate other standard BETE spray nozzles. These deflected fan nozzles are an ideal choice for various applications, including those requiring sanitary options with weld connections and no knurling.
Design Features of the BETE Deflected Fan Nozzles
- Can change nozzles in seconds without tools
- Three-part nozzle, base, gasket, and interchangeable tip
- Exclusive ramped engagement for efficient, automatic alignment
- Threaded adaptors will accommodate other standard BETE nozzles. Shut-off plugs are also available
- Sanitary EZs are available with weld connection and no knurling
Achieving the Extra-Wide Fan Spray Pattern
- The spray pattern is formed by deflecting off an external surface, creating an extra-wide fan spray pattern
- Spray discharge deflected 75° from the inlet axis
| Available Spray Angles | Flow Rate Range |
| 105 - 145° | 0.0177 to 42.5 gpm |
| Available Connection Types | Materials |
|
Brass, 303, 316 |
